⚙️ Key Features:

• Model: LOGO! 12/24RCEO

• Article Number: 6ED1052-2MD08-0BA2

• Power Supply / I/O: 12/24 V DC / Relay

• Inputs/Outputs:

  • 8 Digital Inputs (4 usable as Analog Inputs)

  • 4 Digital Relay Outputs

• Memory Capacity: 400 Function Blocks

• Modular Expandability: Yes – supports additional I/O modules

• Networking: Built-in Ethernet port for programming and communication

• Web Features:

  • Integrated Web Server

  • Support for User-Defined Web Pages

  • Remote Monitoring & Control via Browser

• Cloud Connectivity:

  • MQTT Protocol Support

  • Cloud Connection Ready

• Data Logging: Integrated data logging functionality

• Display: Without display (ideal for compact installations)

• microSD Support: Uses standard microSD card (for program storage & updates)

• Software Compatibility: LOGO! Soft Comfort V8.4 or higher

• Legacy Support: Compatible with older project files

• Certifications & Compliance:

  • RoHS Compliant: Since 30.09.2020

  • WEEE (2012/19/EU) Take-Back Obligation: Yes

  • Export Control Regulations: AL: N / ECCN: EAR99H

  • Country of Origin: China
