Product Description:

The Siemens SIPLUS S7-1500 CPU 1513-1 PN (based on 6ES7513-1AM03-0AB0) is a robust, conformal-coated PLC designed for harsh industrial environments with a wide operating temperature range of -40 °C to +60 °C. It delivers high reliability and performance in outdoor and demanding automation applications while maintaining Siemens’ exceptional S7-1500 efficiency and precision.

🔍 Key Technical Features:

• Model: SIPLUS S7-1500 CPU 1513-1 PN

• Article Number: 6AG1513-1AM03-2AB0

• Base Model: 6ES7513-1AM03-0AB0

• Temperature Range: -40 °C to +60 °C (extended operating range)

• Protection: Conformal coating for moisture, corrosion, and pollution resistance

• Work Memory: 600 KB for program execution

• Data Memory: 2.5 MB for data handling

• Bit Performance: 25 ns – fast cycle times for precision control

• Interface: PROFINET IRT with integrated 2-port switch

• Memory Requirement: SIMATIC Memory Card (mandatory)

• Lifecycle Status: Active Product

• Product Class: A – Standard stock item (returnable per Siemens policy)

• Net Weight: 0.452 kg

• Standard Delivery Time: 30 Days

• Country of Origin: Germany

• Export Control Regulations: AL : N / ECCN : 9N9999

• Environmental Compliance:

  • RoHS Directive: Compliant since 13.09.2024

  • WEEE (2012/19/EU): Take-back obligations supported

  • REACH: Conforms to the latest candidate list

• Classification Codes:

  • eClass: 27-24-22-07

  • ETIM: EC000236

  • IDEA: 3565

  • UNSPSC: 32-15-17-05
